SKW-25 series CNC tube bending machine is designed for the pipe bending , especially for the pillow tube processing on car seat ,  bending diameter on Ø8 ~ 25, wall thickness 1.5mm for copper and aluminum tube or on Ø14mm, wall thickness 2.0mm iron tube, the clamping mechanism using hydraulic control, Y, B, C coordinate driven by servo, machine using microcomputer control. It can realize complex functions such as three-axis simultaneous movement, active and passive bending.

The machine integrates with left and right bending direction function. Two bending heads setting with  parallel arrangement. Parameter setting and operation switching can be set through the  Chinese or English operation interface, which is simple, convenient and reliable. With good stability, repeatability and high efficiency, it is very suitable for the bending of complex pipe fittings.

Device description: Can bend the diameter on 8 ~ 19, wall thickness 1.5mm on the copper tube, aluminum tube or 14mm, wall thickness 2.0mm iron tube.

Function features: For complex pipe to effectively avoid interference position, a pipe clamp, flexible to achieve left and right direction bending.

Longest processing: Active: 1100mm; Through type: 2000mm.

Pneumatic and electrical control, greatly improve the speed of bending.Realize active and passive tube bending.Simple operation, flexible and reliable.

Widely used in air conditioning to the automotive industry complex tube processing.

Four - six axis precision servo control: bending crankshaft, feed shaft, rotation shaft, auxiliary push shaft/lift shaft, translation shaft.

Four - six axis precision servo control: bending crankshaft, feed shaft, rotation shaft, auxiliary push shaft/lift shaft, translation shaft.

Four - six axis precision servo control: bending crankshaft, feed shaft, rotation shaft, auxiliary push shaft/lift shaft, translation shaft.

Four - six axis precision servo control: bending crankshaft, feed shaft, rotation shaft, auxiliary push shaft/lift shaft, translation shaft.

Applicable pipe:copper pipe,aluminum pipe:Features:automatic front plug function;Small R angles can be bent close to 90 degrees.

Power source selection: pneumatic, hydraulic.Three-axis - six-axis precision servo control: bending crankshaft, feeding shaft, rotation shaft/ auxiliary push shaft, lifting shaft, translation shaft.

Pneumatic and electrical control, greatly improve the speed of bending.Realize active and passive tube bending.Simple operation, flexible and reliable.Widely used in air conditioning to the automotive industry complex tube processing.

The machinable pipe diameter can reach Φ 30 × 2.0mm. All actions are electrically controlled.Multi bend radius left or right bend.Precision.high efficiency and environmental .

The machinable pipe diameter can reach Φ 19 × 1.5mm. 7-8 axis electric servo control.Multi bend radius left or right bend.Precision.high efficiency and environmental.
